android 一个应用程序的启动android 程序启动过程，这次主要研究的是具有Activity的android app！package da
android 一个应用程序的启动
android 程序启动过程，这次主要研究的是具有Activity的android app！
package dalvik.system;class NativeStart implements Runnable { private NativeStart() {} private static native void main(String[] dummy); public native void run();}由此部分代码通过JNI进一步激活ZygoteInit 中的main（）由此一个新的Linux进程就启动了，但是在android中已经把Linux这些特新封装起来了，隐藏了linux的一些特性。只流下了：Activity、Service、ContentProvider、BroadcastReceiver。
public static void main(String argv[]) { try { registerZygoteSocket(); EventLog.writeEvent(LOG_BOOT_PROGRESS_PRELOAD_START, SystemClock.uptimeMillis()); preloadClasses(); preloadResources(); EventLog.writeEvent(LOG_BOOT_PROGRESS_PRELOAD_END, SystemClock.uptimeMillis()); // Do an initial gc to clean up after startup gc(); // If requested, start system server directly from Zygote if (argv.length != 2) { throw new RuntimeException( "ZygoteInit.main expects two arguments"); } if (argv[1].equals("true")) { startSystemServer(); } Log.i(TAG, "Accepting command socket connections"); if (ZYGOTE_FORK_MODE) { runForkMode(); } else { runSelectLoopMode(); } closeServerSocket(); } catch (MethodAndArgsCaller caller) { caller.run(); } catch (RuntimeException ex) { Log.e(TAG, "Zygote died with exception", ex); closeServerSocket(); throw ex; } } /** * Helper exception class which holds a method and arguments and * can call them. This is used as part of a trampoline to get rid of * the initial process setup stack frames. */ public static class MethodAndArgsCaller extends Exception implements Runnable { /** method to call */ private final Method mMethod; /** argument array */ private final String[] mArgs; public MethodAndArgsCaller(Method method, String[] args) { mMethod = method; mArgs = args; } public void run() { try { mMethod.invoke(null, new Object[] { mArgs }); } catch (IllegalAccessException ex) { throw new RuntimeException(ex); } catch (InvocationTargetException ex) { Throwable cause = ex.getCause(); if (cause instanceof RuntimeException) { throw (RuntimeException) cause; } else if (cause instanceof Error) { throw (Error) cause; } throw new RuntimeException(ex); } } }当抛出MethodAndArgsCaller caller 异常时，执行：caller.run();mMethod.invoke(null, new Object[] { mArgs });激活了ActivityThread中的main函数，因为main函数为static ，所以invoke第一个参数为null
此异常是间接由startSystemServer();throw的。如下代码：
/** * Prepare the arguments and fork for the system server process. */ private static boolean startSystemServer() throws MethodAndArgsCaller, RuntimeException { /* Hardcoded command line to start the system server */ String args[] = { "--setuid=1000", "--setgid=1000", "--setgroups=1001,1002,1003,1004,1005,1006,1007,1008,1009,1010,3001,3002,3003", "--capabilities=130104352,130104352", "--runtime-init", "--nice-name=system_server", "com.android.server.SystemServer", }; ZygoteConnection.Arguments parsedArgs = null; int pid; try { parsedArgs = new ZygoteConnection.Arguments(args); /* * Enable debugging of the system process if *either* the command line flags * indicate it should be debuggable or the ro.debuggable system property * is set to "1" */ int debugFlags = parsedArgs.debugFlags; if ("1".equals(SystemProperties.get("ro.debuggable"))) debugFlags |= Zygote.DEBUG_ENABLE_DEBUGGER; /* Request to fork the system server process */ pid = Zygote.forkSystemServer( parsedArgs.uid, parsedArgs.gid, parsedArgs.gids, debugFlags, null); } catch (IllegalArgumentException ex) { throw new RuntimeException(ex); } /* For child process */ if (pid == 0) { handleSystemServerProcess(parsedArgs); } return true; } /** * Finish remaining work for the newly forked system server process. */ private static void handleSystemServerProcess( ZygoteConnection.Arguments parsedArgs) throws ZygoteInit.MethodAndArgsCaller { /* * First, set the capabilities if necessary */ if (parsedArgs.uid != 0) { try { setCapabilities(parsedArgs.permittedCapabilities, parsedArgs.effectiveCapabilities); } catch (IOException ex) { Log.e(TAG, "Error setting capabilities", ex); } } closeServerSocket(); /* * Pass the remaining arguments to SystemServer. * "--nice-name=system_server com.android.server.SystemServer" */ RuntimeInit.zygoteInit(parsedArgs.remainingArgs); /* should never reach here */ } /** * The main function called when started through the zygote process. This * could be unified with main(), if the native code in finishInit() * were rationalized with Zygote startup.<p> * * Current recognized args: * <ul> * <li> --nice-name=<i>nice name to appear in ps</i> * <li> <code> [--] <start class name> <args> * </ul> * * @param argv arg strings */ public static final void zygoteInit(String[] argv) throws ZygoteInit.MethodAndArgsCaller { // TODO: Doing this here works, but it seems kind of arbitrary. Find // a better place. The goal is to set it up for applications, but not // tools like am. System.setOut(new AndroidPrintStream(Log.INFO, "System.out")); System.setErr(new AndroidPrintStream(Log.WARN, "System.err")); commonInit(); zygoteInitNative(); int curArg = 0; for ( /* curArg */ ; curArg < argv.length; curArg++) { String arg = argv[curArg]; if (arg.equals("--")) { curArg++; break; } else if (!arg.startsWith("--")) { break; } else if (arg.startsWith("--nice-name=")) { String niceName = arg.substring(arg.indexOf('=') + 1); Process.setArgV0(niceName); } } if (curArg == argv.length) { Slog.e(TAG, "Missing classname argument to RuntimeInit!"); // let the process exit return; } // Remaining arguments are passed to the start class's static main String startClass = argv[curArg++]; String[] startArgs = new String[argv.length - curArg]; System.arraycopy(argv, curArg, startArgs, 0, startArgs.length); invokeStaticMain(startClass, startArgs); } /** * Invokes a static "main(argv[]) method on class "className". * Converts various failing exceptions into RuntimeExceptions, with * the assumption that they will then cause the VM instance to exit. * * @param className Fully-qualified class name * @param argv Argument vector for main() */ private static void invokeStaticMain(String className, String[] argv) throws ZygoteInit.MethodAndArgsCaller { // We want to be fairly aggressive about heap utilization, to avoid // holding on to a lot of memory that isn't needed. VMRuntime.getRuntime().setTargetHeapUtilization(0.75f); Class<?> cl; try { cl = Class.forName(className); } catch (ClassNotFoundException ex) { throw new RuntimeException( "Missing class when invoking static main " + className, ex); } Method m; try { m = cl.getMethod("main", new Class[] { String[].class }); } catch (NoSuchMethodException ex) { throw new RuntimeException( "Missing static main on " + className, ex); } catch (SecurityException ex) { throw new RuntimeException( "Problem getting static main on " + className, ex); } int modifiers = m.getModifiers(); if (! (Modifier.isStatic(modifiers) && Modifier.isPublic(modifiers))) { throw new RuntimeException( "Main method is not public and static on " + className); } /* * This throw gets caught in ZygoteInit.main(), which responds * by invoking the exception's run() method. This arrangement * clears up all the stack frames that were required in setting * up the process. */ throw new ZygoteInit.MethodAndArgsCaller(m, argv); }
